PLD Concrete Batching Machine

Related Concrete Equipment

● Products :PLD Concrete Batching Machine

● Type :Related Concrete Equipment

● Brand :HAMAC

● Origin :China

If you want to know more details, please contact us, we will reply you as soon as possible.

Product Introduction
PLD series concrete batching machine is automatic batching equipment supporting a mixer. It can automatically complete the ratio of sand, stone, cement and other kinds of materials 3-6 (secondary aggregate grading concrete) ingredients procedures designed according to user's concrete requirement.
Benefits & Features
1. High precision electric weighing, PC+PLC control;
2. Digital display on the screen, Reasonable layout,
3. Compact structure, Easy operation,
4. Reliable performance.

Tags: concrete pump boom in General of Santosconcrete pump pipes for sale in San Pedroon site concrete batching plantsmall concrete mixers for sale in Wenzhen Yuba

More Info
Model PLD800 PLD1200 PLD1600 PLD2400 PLD3200 PLD4800
Cubage of storage hopper 2m3 2.2m3 3.7m3 12m3 20m3 25m3
Cubage of weighing hopper 0.8m3 1.2m3 1.6m3 2.4m3 3.2m3 4.8m3
Output rate 48m3/h 60m3/h 80m3/h 120m3/h 160m3/h 280m3/h
Accuracy of batching ±2% ±2% ±2% ±2% ±2% ±2%
Max weighing value 1500Kg 2000Kg 3000Kg 4000Kg 5000Kg 8000Kg
Aggregate types
for batching
2-3 2-4 2-4 3-4 3-4 4
Feeding height 3000mm 3000mm 3000mm 3200mm 3500mm 3800mm
Speed of belt conveyor 1.25m/s 1.25m/s 1.25m/s 1.0m/s 1.0m/s 1.6m/s
Power (2-3)x3Kw (2-4)x3Kw (2-4)x3Kw 11Kw 11Kw 15Kw
Overall weight 2500Kg 2900-3900-4900Kg 3500-4750-5750Kg 8500-10500Kg 10200-12600Kg 13600Kg
Note: Our products are being updated constantly, all rights reserved by HAMAC.

Backhoe Loader

Wheel Loader

Cement Silo

PLD Concrete Batching Machine

Cement Mortar Foam Machine

LSY series Screw Conveyor

Technical support and after-sales service team in the Philippines

If you need other concrete pumps for sale, such as Concrete Mixer,Concrete Batching Plant,Concrete Mixer With Pump,Self loading Concrete Mixer Truck,Concrete Pumps,Concrete Truck Mixer,Concrete Placing Boom,Concrete Block Making Plant,Skid Steer Loaders,Related Concrete Equipment, for sale…. we also could supply according to your requirements. In a word, Hamac group is an integrative suppliers of concrete pumps, combining manufacturing, selling and servicing together, we are professional and reliable in supplying concrete pumps for sale.

Technical support and after-sales service team in the Philippines

1. 24 hours online service freely;

2. One year warranty time except for vulnerable parts.

3. Life long maintenance service;

4. Send engineers to install and debug the equipment;

5. Freely train operators to use and maintain skills;

6. Send engineers to fix failure if customers need;

7. Supply all kinds of spare parts;
