JS series Concrete Mixer

Concrete Mixer

● Products :JS series Concrete Mixer

● Type :Concrete Mixer

● Brand :HAMAC

● Origin :China

If you want to know more details, please contact us, we will reply you as soon as possible.

Product Introduction
JS series concrete mixer is a kind of double shafts forced type mixer, it can be used separately and can be used together with a concrete batching machine to be a simple type concrete batching plant. It is being widely used in various scale of prefabricate concrete parts factory, and much construction of road and bridge, dam, port and so on. It could be used to produce dry concrete, plastic concrete, fluidity concrete, lightweight aggregate and various kinds of mortar.

Hot Sale in stock: HMC3.5 self-loading mixer - SICOMA Mixer - HZS60 Concrete Mixing Plant - DHBT40 concrete pump - DHBT40 concrete pump - HBT15 Concrete mixer and pump - Get quote or inquiry!

Benefits & Features
1. Special drum prolongs the service life of the steel wire rope.
2. Precise mechanical parts.
3. High-quality wear-resistant alloy casting parts and advanced production technology ensure the clearance of the mixing blades and the liner plate well-distributed.
4. The test run with dry aggregate supplies sufficient reasons for customers to choose Hamac.
5. Concrete intensity test proves the excellent performance of the mixing equipment.

Tags: concrete mixing plant in Quezon concrete agitators in The law of depiction concrete mixer machine in Quezon use of concrete pumpconcrete mixture truck in Iloilocompact backhoe loaderconcrete equipment for sale in Caloocan

More Info
Model JS500 JS750 JS1000 JS1500 JS2000 JS3000 JS3500 JS4000
Discharging volume (L) 500L 750L 1000L 1500L 2000L 3000L 3500L 4000L
Feeding volume (L) 800L 1200L 1600L 2400L 3200L 4800L 5600L 6400L
Capacity ≥25m³/h ≥37.5m³/h ≥50m³/h ≥75m³/h ≥100m³/h ≥150m³/h ≥180m³/h ≥200m³/h
Maximum aggregate size (pebble/gravel)mm 40/50 40/60 60/80 80/100 80/100 80/120 80/120 80/120
Cycle time (S) 72 72 60 60 60 60 60 60
Total weight (kgs) 4000 5500 8700 11300 15000 11450 12000 19000
Discharge height (m) 3.8 3.8 3.8 3.8 3.8 3.8 3.8 3.8
Mixing blade Rotary speed 35r/min 26r/min 29.6r/min 24.5r/min 24.5r/min 21r/min 21r/min 21r/min
Quantity 2×7 2×7 2×8 2×8 2×8 2x10 2x10 2x11 2x12
Mixing motor Model Y180M-4 Y200L-4 Y180M-4 Y225M-6 Y250M-6 Y280M-6 Y280M-6 Y315S-6
Power 18.5kw 30kw 2x18.5kw 2x30kw 2X37kw 2X55kw 2X55kw 2X55kw
Hoist motor Model YEZ1325-4-B5 YEZ132M-4-B5 YEZ160L-4 YEZ180L-4 YEJ180L-4 Y25M -4 Y25M -4 Y25M -4
Power 5.5KW 7.5KW 15KW 18.5KW 22KW 2 × 55 kw 2 ×55 kw 2 × 75 kw
Pump motor Power 1.1KW 1.1KW 3KW 3KW 4KW 5KW 5KW 6KW

Any change of technical data shall not be advised additionally.

Concrete Mixer with Pump

Self-loading Mobile Concrete Mixer

SICOMA Double Shaft Concrete Mixer

JZ series Concrete Mixer

JZR Diesel Driven Concrete Mixer

European Tech.Twin shaft Concrete Mixer

MP Planetary Concrete Mixer

SICOMA Planetary Concrete Mixer

Technical support and after-sales service team in the Philippines

If you need other concrete pumps for sale, such as Concrete Mixer,Concrete Batching Plant,Concrete Mixer With Pump,Self loading Concrete Mixer Truck,Concrete Pumps,Concrete Truck Mixer,Concrete Placing Boom,Concrete Block Making Plant,Skid Steer Loaders,Related Concrete Equipment, for sale…. we also could supply according to your requirements. In a word, Hamac group is an integrative suppliers of concrete pumps, combining manufacturing, selling and servicing together, we are professional and reliable in supplying concrete pumps for sale.

Technical support and after-sales service team in the Philippines

1. 24 hours online service freely;

2. One year warranty time except for vulnerable parts.

3. Life long maintenance service;

4. Send engineers to install and debug the equipment;

5. Freely train operators to use and maintain skills;

6. Send engineers to fix failure if customers need;

7. Supply all kinds of spare parts;
